| MODEL | SC–520LR |
|---|---|
| Chamber Sizes | 23.6″/600mm 23.6″/600mm |
| Chamber Height | 3″+5″/75+200mm |
| Distance Between Seal Bars | 18″/450mm |
| Seal Bar Length | 21.3″x 2/540mm |
| Vacuum Pump Capacity | 21m3/h (1–1/4hp) |
| Voltage | 110V / 1ph / 60Hz / 16amp |
| Machine Size L x W x H |
24″x30″x36″ 615x756x916mm |
| Machine Weight | 310 lbs. (140kg) |
Specifications are subject to change without notice.
| MODEL | SC–680LR |
|---|---|
| Chamber Sizes | 35.8″/900mm 26″/665mm |
| Chamber Height | 8″/200mm |
| Distance Between Seal Bars | 26″/665mm |
| Seal Bar Length | 20.5″x 2/520mm |
| Vacuum Pump Capacity | 40m3/h (2hp) |
| Voltage | 230V / 3ph / 60Hz / 8amp |
| Machine Size L x W x H |
35″x26″x39″ 900x665x1000mm |
| Machine Weight | 500 lbs. (227kg) |
Specifications are subject to change without notice.
| MODEL | SC–800LR |
|---|---|
| Chamber Sizes | 38″/960mm 33.5″/850mm |
| Chamber Height | 10″/250mm |
| Distance Between Seal Bars | 28.5″/725mm |
| Seal Bar Length | 26″x 2/660mm |
| Vacuum Pump Capacity | 63m3/h (3hp) |
| Voltage | 230V / 3ph / 60Hz / 11amp |
| Machine Size L x W x H |
38″x32″x40″ 960x805x1020mm |
| Machine Weight | 600 lbs. (272kg) |
Specifications are subject to change without notice.
