Additional information
Weight | 160 lbs |
---|
SKU: VAC310-2Bar
Categories: Chamber Vacuum Sealers, VacSeries, Vac310 Products
PROGRAMMABILITY, ACCESSORY CAPABILITY, SKIP FUNCTIONALITY – NOW AVAILABLE!
The JVR Vac310 (2 Bar) – Chamber Vacuum Sealer, may be just a tabletop machine. But it’s a workhorse and built with durability and speed in mind. Capable of sealing up to 16″x 16″ vacuum pouches, the Vac310 stands apart from its competition.
At the heart of every vacuum sealer is the vacuum pAt the heart of every vacuum sealer is the vacuum pump. The Vac310 is equipped with a highly efficient 1.25 hp vacuum pump that outperforms most 1.5 hp vacuum pumps. Capable of removing 99% of the air in just 20 seconds, the Vac310 vacuum chamber sealer is built for speed and efficiency.
The transparent acrylic lid on our unit serves two purposes. The primary function is to view the product during operations. Optimal viewing is critical when problems arise so that the customer can diagnose the issue more rapidly under our direction. The second purpose of the lid is to promote faster vacuum cycle times for lower-profile products. The 7″ maximum chamber height provides ample room for sealing high-profile products.
The JVR Vac310 is equipped with a massive 10mm heat strip, otherwise known as seal wire. Typically speaking, vacuum chambers are paired with a dual 3mm heat strip in their seal bar assembly. JVR Industries wanted to reduce heat strip changeover times and grant extra insurance in the seal integrity.
–
The JVR Vac310 is one of the only at-home use, industrial-style chamber vacuum sealers with a specifically designed bar to seal off retort pouches and mylar bags. The perfect companion for those who are doing retort canning, freeze-dried goods, MREs, and so on! If you need a retort vacuum sealer, look no further! The Vac310 is the perfect tool to get the job done!
VacSeries Models | Vac310 (2 Bar) | Vac310 (1 Bar) |
---|---|---|
Machine Size (W, D, H) | 19.7″ x 21.5” x 20“ (LID OPEN [H] 30.3″) | 19.7″ x 21.5” x 20“ (LID OPEN [H]: 30.3″) |
Chamber Size (W, D, H) | 16.3″ x 16.5″ x 6.75“ | 16.3″ x 16.5″ x 6.75“ |
Heat Strip Width | 10mm | 10mm |
Seal Bar Length | 16″ (x2) | 16″ |
Seal To Chamber Back (L) | N/A | 14.5″ |
Seal To Seal (L) | 12.6″ | N/A |
Max Pouch Size | 16″ x 16″ | 16″ x 20″ |
Machine Weight | 145 lbs | 145 lbs |
Amperage | 14 Amps max | 14 Amps max |
Voltage | 110V / 1ph / 60Hz | 110V / 1ph / 60Hz |
Vacuum Pump Capacity | 20m3/h flow rate 1 1/4 hp | 20m3/h flow rate 1 1/4 hp |
Accessory Capable? | Yes | Yes |
Retort Capable? | Yes | Yes |
Pump Type | Oil Lubricated Rotary Vane Vacuum Pump | Oil Lubricated Rotary Vane Vacuum Pump |
Hinging Body | No | No |
dB at Room Temp | 70 | 70 |
Specifications are subject to change without notice.
Package Contents:
1 Starter Bottle of Oil (VacOil)
Funnel
2 – Heat Strip Replacement
2- Seal Bar Tape Replacement
Lid Chamber Gasket Replacement
Filler Plates
Sample Pack of Chamber Vacuum Pouches (VacPouch)
Features:
Stainless steel body
Reinforced stainless steel chamber
Fast cycle times
Simple digital controls
Transparent acrylic lid to view the product
Oil lubricated, high flow, vacuum pump
Toolless seal bar removal
10mm extra-wide seal wire
Every chamber vacuum sealer in the JVR VacSeries line undergoes a thorough and rigorous quality inspection right in Lancaster, NY. Each chamber vac is tested for full vacuum draw, proper control board functionality, vacuum leaks, & more! Our 50+ years of experience is used in ensuring your future chamber vacuum sealer meets a high standard of performance before it leaves our facility.
